3M™ Diamond Grade™ DG³ Reflective Sign Sheeting
Commitment to achieving the best possible traffic safety outcomes starts with 3M™ Diamond Grade™ DG³ Sheeting. It provides brightness and visibility with the highest optical efficiency of 3M's sheeting products by returning more light to drivers in a range of vehicle types.
DG³ sheeting has twice the brightness of 3M's lower-grade reflective sign sheeting
-
-
3M’s “full-cube” retroreflective technology greatly increases the visibility of road signs for drivers across a range of vehicle types and sign geometries. These performance improvements are enabled by “100% active area” full cube retroreflectors that result in higher efficiency sheeting as compared to conventional retroreflective sheeting. Even signs in the most disadvantaged locations perform better with Diamond Grade™ DG³ sheeting.
58% Retroreflection efficiency (29% + 29%) is ideal for large and small vehicles. Increasing the overall total retroreflective efficiency serves the greatest segment of night-time drivers of all vehicle types.²
Why DG³ reflective sign sheeting?
-
Maximise Reflected Light
The truth is, not all Class 3 sheeting is created equal. Some Class 3 sheeting is produced using truncated cube technology. Truncated cubes have an active area of 67% or less, resulting in less-efficient sheeting. 3M™ Diamond Grade™ DG3 Sheeting uses full-cube microprism technology to create bright, reflective road signs that surpass the Class R3A and R3B requirements of DIN 67520 and meet Class R3C-UK of UK National Annex to EN 12899-1. Help make your roads safer and easier to navigate with full-cube reflective sheeting that gives 100%.
Learn how not all Class 3 Sheeting is created equal (PDF, 1.2 MB)
Brighter Signs for Safer Roads – your guide to more visible signs (PDF, 1.38 KB)
-
Visible Signs Improve Road SafetyAccording to one study, brighter sign sheeting helped reduce the number of crashes by 25-46% (over a three- to six-year period) in locations where the more reflective sheeting was installed.* Class 3 / Type XI sheeting is brighter, more reflective and more conspicuous than standard beaded sheeting (or…than lower grade sheeting). This helps drivers see and react to road signs sooner and with greater confidence.
*Ripley, D., Howard R. Green Company, ITE AB04H313.
Download the white paper on traffic sign brightness (PDF, 650 KB)
DG³ reflective sign sheeting demonstration videos
Watch our demonstration videos to see for yourself the advantages of choosing Diamond Grade™ DG³ reflective sign sheeting.
-
Laser Light Demonstration
This demonstration shows how 3M's microprismatic fluorescent sheeting can significantly improve critical sign visibility during night-time conditions. The larger cone of retroreflection illustrates how drivers of both large and small vehicles are better served by Diamond Grade™ DG³ sheeting.
Click the image above to watch the video (1:58)
-
-
Free webinar: Brighter signs for safer roads.
Improving road safety with 3M™ Diamond Grade™ DG³ Reflective Sheeting.Register for our free webinar on 27 April 2023 discussing the benefits of 3M™ Diamond Grade™ DG³ Reflective Sign Sheeting for both road users and providers.
Don’t miss this opportunity to learn more about the difference bright signage can make and put your questions to 3M road safety experts.
Additional benefits of 3M™ Diamond Grade™ DG³ reflective sign sheeting
With its life expectancy of 12 years, Diamond Grade™ DG³ reflective sign sheeting provides protection for longer than 3M's lower-grade sign sheeting.
-
Increased reaction time for driversBrighter signs give drivers more time to react. During the day, and especially at night, DG³ Reflective Sheeting can make a difference by making signage brighter and more visible as compared to our High Intensity Prismatic sheeting, giving drivers more time to react.
Brighter sheeting is more visible to drivers and has been shown to increase safety by helping cut night-time accidents by 25% to 46%.¹
-
Can help reduce lighting costs"With the highest brightness and retroreflectivity ratings in the industry, Diamond Grade™ DG³ can safely lower installed road lighting costs by up to $150,000 per km, and annual lighting maintenance by up to $15,000 per km."
— The Handbook of Road Safety Measures, 2nd Edition. Rune Elvik, 2009.
-
Long-lasting and less maintenance costWith its warranty of 12 years, it provides protection longer than lower-grade sign sheeting. It may also require less maintenance and reduce energy expenses.
Why upgrade to Diamond Grade™ DG³
The difference between High Intensity Prismatic and Diamond Grade™ DG³ reflective sign sheeting.
-
Brighter signs, safer roads. During the day, and especially at night, 3M™ Diamond Grade™ DG³ reflective sign sheeting can make a difference by making signage brighter and more visible, giving drivers more time to react.
High Intensity Prismatic Sheeting meets middle grade performance standards and EN 12899-1 Class RA2. This reflective sign sheeting uses polycarbonate cube corner technology and is often used for reflective traffic and road signs.
Diamond Grade™ DG³ reflective sheeting meets Class RA3 and R3B of DIN 67520 and Class R3C-UK of UK National Annex to EN 12899-1. This highly reflective sign sheeting uses efficient full-cube prismatic technology that reflects more light back to its source than High Intensity Prismatic sheeting.
Main reasons to upgrade to DG³
-
Safer roadsAccording to one study, over a three to six-year period, crash numbers dropped by 25% to 46% where brighter signs, like those with DG³ reflective sign sheeting, were installed.²
Road Signs can make a difference during the day, and especially at night, by using 3M™ Diamond Grade™ DG³ Reflective Sheeting. -
Brighter signsSignificantly brighter signs are manufactured with 3M’s Full Cube Technology. This represents optimal performance in retroreflective technology, with optic elements that are nearly 100% efficient, resulting in sign sheeting that returns almost 60% of available light. Signs are noticeably brighter and more legible at a greater distance. 12-year warranty backed by 3M.
-
Broad observation anglesFull cube technology reflects light at broad observation angles, helping drivers in all vehicle sizes to see your sign.
